Galvanized Steel Frame Warehouse 30m x 50m Fireproof Construction

Brand Name : YDX

Model Number : YDX-8SGV

Certification : CE ISO SGS

Place of Origin : CHINA,QINGDAO

MOQ : 10-10000 square meters

Price : $30.00-$65.00

Payment Terms : T/T

Supply Ability : 10000 tons/month

Delivery Time : 20-30 works days

Packaging Details : Exported standard packing

Fireproof : fire-resistant

Window : Aluminum Sliding Window

Column : Squre Tube

Highlight : Painted Steel Structure Warehouse

Installation Method : Bolted or Welded

Roof Cladding : Color Steel Sheet(sandwich Panel)

Product Insulation : Thermal Insulation

Roof Purlin : Z/C section Purlin

Structure Type : Frame

Frame Type : Steel Frame

Earthquake Resistance : Strong

Windows : Aluminum

Seismic Design : High Seismic Zone

Installation Time : Short

Aesthetics : Modern

Construction Type : Frame

Cost : Moderate

Product Resistance : Corrosion Resistant

Finish : Galvanized/Painted/Cladding

Roof : Glass Wool, EPS, PU

Product Fire Resistance : Fireproof

Door : Sliding Door or Rolling Door

Contact Now

CE Prefab Warehouse Building Galvanized Economical Welded H Type Steel

Maximize space

One of the best features of steel buildings is that they can be constructed without any interior columns that might take up valuable floor space or interfere with interior operations. The simple fact that machines and laborers do not have to maneuver around massive interior columns can save countless hours of work. It also is incredibly important in maximizing space for storage.

Expansion-friendly

Sometimes clients have told us that they intend to extend their building in future years as their business grows. With steel buildings, this can actually be a very simple process. If the original building was properly erected and well-maintained, you can easily expand it rather than constructing an entirely new structure.

Durable

We always like to highlight the superior strength and durability of steel over other building materials. Warehouses often are used for commercial and industrial spaces, meaning that they contain heavy objects or heavy machinery that if mishandled can cause significant structural damage. Steel buildings are better able to withstand this type of impact damage.

Energy effiency

Energy efficiency is one of the primary concerns of any business owner. You want to make sure that the building is affordable as possible in the future. With steel buildings, it is often important to insulate your building for proper temperature control. Nothing can hurt the efficiency and affordability of a building worse than super-high heating or cooling bills. Lucky for you, metal is reflective, and therefore can reflect heat, making buildings less warm in the hot, sunny months. Another reason metal buildings and roofs can stay cooler is due to the addition of chemicals designed to reflect infrared wavelengths, which can be added to the metal building paint.

Product Application
Light Frame Steel Construction Hangar Design Prefabricated Steel Structure Factory Building Workshop warehouse
A pre-engineered steel building is a modern technology where the complete designing is done at the factory and the building components are brought to the site and then fixed/jointed at the site, all is bolt connection, no need any welding!
An efficiently designed pre-engineered building can be lighter than the conventional steel buildings by up to 30%. Lighter weight equates to less steel and potential price savings in structural framework.
SPECIFICATION FOR STEEL STRUCTURE BUILDING
Main Steel Frame Steel Column & Beam 1. Material: Q345B (S355JR) or Q235B(S235JR)/ Welded/Hot Rolled H section steel
2. Surface: Hot Dip Galvanized or Painted;
3. Connection: All Bolts Connection;
Supporting System Roof Purlin C or Z Section Steel, Q235B
Wall Purlin C or Z Section Steel, Q235B
Bracing Steel Rod, Q235B
Cross Support Steel Rod, Q235B
Column Support Angle Steel; Steel Rod; Q235B
Angle Brace Angle steel,Q235B
Tie Bar Steel Pipe,Q235B
Roof & Wall System 1. Single Colorful Corrugated Steel Sheet;
Thickness: 0.3-0.8mm
2. Sandwich Panel with EPS, Rock Wool, Fiberglass,PU;
Thickness: 50-150mm;
Accessories Door Sliding; Rolled Up Door (Manual/Auto)
Window Aluminum Alloy; PVC;
Downspout PVC pipe;
Gutter Galvanized Steel Sheet; Stainless Steel
Ventilator Stainless Steel Turbine Ventilator
Skylight Belt FRP or PC semi-transparent Skylight Belt
Flash Color Steel Sheet
Fittings Anchor Bolt; High Strength Bolt; Standard Bolt, Self-tapping nail etc

Galvanized Steel Frame Warehouse 30m x 50m Fireproof Construction

Galvanized Steel Frame Warehouse 30m x 50m Fireproof Construction

Packing & Loading:

All the structure components, panels,bolts and sort of accessories will bewell packed with standard package suitable ocean transportation and loaded into 40’HQ.

All the products are loaded at the loading site of our factory using crane and forklift by our skilled workers,who will prevent the goods to be damaged.

Galvanized Steel Frame Warehouse 30m x 50m Fireproof Construction

The following question we need to know before making the price. Just feel free to fill what you know.

1 Location (where will be built?) _____country, area
2 Size: length*width*height _____mm*_____mm*_____mm
3 wind load (max. wind speed) _____kn/m2, _____km/h, _____m/s
4 snow load (max. snow height) _____kn/m2, _____mm
5 anti-earthquake _____level
6 brickwall needed or not If yes, 1.2m high or 1.5m high
7 thermal insulation If yes, EPS, fiberglass wool, rockwool, PU sandwich panels will be suggested; . if not, the metal steel sheets will be ok. The cost of the latter will be much
lower than that of the former
8 door quantity & size _____units, _____(width)mm*_____(height)mm
9 window quanity & size _____units, _____(width)mm*_____(height)mm
10 crane needed or not If yes, _____units, max. lifting weight____tons; max. lifting height _____m
